TOA A-2060 Mixer Power Amplifier
Call for Price
The A-2060 is a high cost-performance mixer power amplifier suited for broadcasting paging or background music in schools, offices, shops, factories, mosques, churches and large rooms.
Description
| Power Source | 220 – 240 V AC, or 24 V DC |
|---|---|
| Rated Output | 60 W |
| Power Consumption | 72 W (EN60065), 4 A (DC operation at rated output) |
| Frequency Response | 50 – 20,000 Hz (±3 dB) |
| Distortion | 1% or less at 1 kHz, 1/3 rated power |
| Input | MIC 1: -60 dB*, 600 Ω, balanced, DIN type (5 pins) MIC 2, 3: -60 dB*, 600 Ω, balanced, phone jack AUX 1, 2: -20 dB*, 10 kΩ, unbalanced, RCA pin jack Mute: Contact pin 4 – 5 closure input (for MIC 1) |
| Output | Speaker out: Balanced (floating), M3.5 screw terminal, distance between barriers: 8.3 mm (0.33″) High impedance: 170 Ω (100 V), 83 Ω (70 V) Low impedance: 4 Ω (15.5 V) Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack |
| Phantom Power | DC +21 V (MIC 1) |
| S/N Ratio | 60 dB or more |
| Tone Control | Bass: ±10 dB at 100 Hz Treble: ±10 dB at 10 kHz |
| Muting | MIC 1 overrides other input signals with 0 – 30 dB attenuation by mute terminal contact in MIC 1 DIN type connector. |
| Finish | Panel: ABS resin, black Case: Steel plate, black |
| Dimensions | 420 (W) × 100.9 (H) × 280.3 (D) mm (16.54″ × 3.97″ × 11.04″) |
| Weight | 7 kg (15.43 lb) |
