Call for Price

  • 35 IR LED
  • 25 Meters Effective Distance
  • 1/3″ color CCD sensor with SONY Effio DSP
  • Super High Resolution
  • Low light sensitivity of 0.05 Lux at F1.4, 0 Lux (IR ON)
  • IP67, suitable for outdoor use
  • Day and night features for 24-hour surveillance


Pick up Element1/3″ H.R. Color CCD image sensor with SONY Effio DSP
Number of Pixel771(H) x 492(V) <NTSC> 753(H) x 582(V) <PAL>
ResolutionSuper High Resolution
Min. Illumination0.05 Lux / F1.4, 0 Lux (IR ON)
IR LED35 Units
Effective RangeUp to 25 m
S / N Ratio ( Signal to Noise )More than 48dB (AGC off)
Electronic Shutter1/60 (1/50) to 1/100,000 sec
Lensf6.0mm / F1.4
Lens Angle54°
Color Rolling SuppressYES
White BalanceATW
IP RatingIP67
Video Output1.0 Vp-p composite, 75Ω
Startup Temperature0˚C~40˚C
Operating Temperature-20˚C~40˚C
Power SourceDC12V ±10%
Current Consumption70mA (IR OFF), 400mA (IR ON)
Dimensions (mm)**142(H) x 75(F)
